Light Duty Accumulating Roller Chain Conveyor
mk Part Number: SRF-P 2045
Request a Quote
Product Information for Light Duty Accumulating Roller Chain Conveyor
The accumulating roller chain conveyor, SRF-P 2045, is ideal for a process requiring many light weight small pallets to be accumulated. The accumulating roller chain provides a low back pressure conveying surface; which allows for many pallets to be stacked in a straight. The use of mk pneumatic stopping devices allows for small pallets to be released from accumulation one at a time, or in other levels as your job requires.
Conveyor Details:
- Frame: Constructed out of mk anodized aluminum extrusion with a UHMW-PE wear surface, 98 mm tall x 45 mm wide lane, single t-slot per side
- Width: Designed for pallets 240 mm wide up to 400 mm wide
- Load: Up to 80 lbs. per pallet load, 1,650 lbs. per drive
- Speed: Up to 90 fpm
- Length: Up to 20,000 mm
- Voltage: All standard US, Mexico and Canadian voltages
- Chain: Accumulating Roller Chain, plastic or steel rollers
- Side Rails: Incorporated into the frame design
- Stands: Compatible with all mk stand designs
- Modules: A wide selection available, refer to System Modules page
Catalogs, Resources & Downloads for Light Duty Accumulating Roller Chain Conveyor
Technical Specifications for Light Duty Accumulating Roller Chain Conveyor
- Constructed using our mk 2045 series structural profile
- 98 mm tall anodized aluminum frame
- T-slots along the length of the conveyor for ease of mounting stands, side rails, and custom accessories
- The chain returns within the frame profile
- This provides a safer design
- A removable slot cover allows access to chain for cleaning and maintenance
- UHMW-PE slider bed with integrated side rail edge
- Dual sealed bearings for low maintenance design
- Positively driven via sprocket – allows conveyor to operate in either direction
- Maintenance free dual-sealed ball bearings
- Compatible with all mk 50 system profiles and components and most mk 40 system profiles and components
- CE Models available
